性能与特点：
采用钢板焊接结构，液压传动，氮气缸回程，操作方便，性能可靠，外形美观。
刃口间隙调整有指示牌指示，调整轻便迅速。
设有灯光对线照明装置，并能无级调节上刀架的行程量。
工作区采用栅栏式人身安全保护装置。
后挡料尺寸及剪切次数有数字显示装置。
技术参数：
|
型 号 |
剪板尺寸 |
剪切角 |
空行程次数 |
后挡料架调 |
主电机 |
|
(T×W)mm |
( °) |
time/min |
mm |
kw |
|
QC12Y-4×3200 |
4×3200 |
1°30′ |
18 |
20~500 |
5.5 |
|
QC12Y-6×2500 |
6×2500 |
1°30′ |
18 |
20~500 |
7.5 |
|
QC12Y-6×3200 |
6×3200 |
1°30′ |
14 |
20~500 |
7.5 |
|
QC12Y-6×4000 |
6×4000 |
1°30′ |
14 |
20~500 |
7.5 |
|
QC12Y-6×5000 |
6×5000 |
1°30′ |
10 |
20~600 |
11 |
|
QC12Y-6×6000 |
6×6000 |
1°30′ |
8 |
20~500 |
11 |
|
QC12Y-8×2500 |
8×2500 |
1°30′ |
16 |
20~500 |
11 |
|
QC12Y-8×3200 |
8×3200 |
1°30′ |
12 |
20~500 |
11 |
|
QC12Y-8×4000 |
8×4000 |
1°30′ |
10 |
20~500 |
11 |
|
QC12Y-8×5000 |
8×5000 |
1°30′ |
8 |
20~500 |
15 |
|
QC12Y-8×6000 |
8×6000 |
1°30′ |
7 |
20~500 |
15 |
|
QC12Y-10×2500 |
10×2500 |
1°30′ |
14 |
20~500 |
15 |
|
QC12Y-10×3200 |
10×3200 |
1°30′ |
12 |
20~500 |
15 |
|
QC12Y-10×4000 |
10×4000 |
1°30′ |
12 |
20~500 |
15 |
|
QC12Y-12×2500 |
12×2500 |
1°30′ |
16 |
20~500 |
18.5 |
|
QC12Y-12×3200 |
12×3200 |
1°30′ |
14 |
20~500 |
18.5 |
|
QC12Y-12×4000 |
12×4000 |
1°30′ |
14 |
20~600 |
18.5 |
|
QC12Y-12×5000 |
12×5000 |
1°30′ |
7 |
20~600 |
22 |
|
QC12Y-12×6000 |
12×6000 |
1°30′ |
6 |
20~600 |
22 |
|
QC12Y-12×8000 |
12×8000 |
1°30′ |
5 |
20~600 |
22 |
|
QC12Y-16×2500 |
16×2500 |
2° |
14 |
20~600 |
22 |
|
QC12Y-16×3200 |
16×3200 |
2° |
12 |
20~600 |
22 |
|
QC12Y-16×4000 |
16×4000 |
2° |
8 |
20~600 |
22 |
|
QC12Y-20×2500 |
20×2500 |
2°30′ |
5 |
20~600 |
30 |
|
QC12Y-20×3200 |
20×3200 |
2°30′ |
5 |
20~600 |
30 |
|
QC12Y-20×4000 |
20×4000 |
2°30′ |
5 |
20~600 |
30 |
|
QC12Y-25×2500 |
25×2500 |
2°30′ |
6 |
20~600 |
37 |
|
QC12Y-25×3200 |
25×3200 |
2°30′ |
6 |
20~600 |
37 |
|
QC12Y-25×4000 |
25×4000 |
2°30′ |
6 |
20~600 |
37 |
|
QC12Y-32×2500 |
32×2500 |
3° |
5 |
20~600 |
37 |
|
QC12Y-32×3200 |
32×3200 |
3° |
5 |
20~600 |
37 |
|
QC12Y-40×2500 |
40×2500 |
3° |
5 |
20~600 |
45 |
|
QC12Y-40×3200 |
40×3200 |
3° |
5 |
20~600 |
45 |
|
QC12Y-50×3000 |
50×3000 |
3° |
5 |
20~600 |
90×3 |
|
QC12Y-50×6000 |
50×6000 |
3° |
5 |
20~600 |
90×5 |
|
QC12Y-60×3500 |
60×3500 |
3°30′ |
5 |
20~600 |
90×4 |
